MITSUBISHI MITSUBISHI A2ACPUP21 Price

Convert connector to screw relay terminal.
According to the location of the connection equipment distribution module. Motor series: medium inertia, medium capacity.
Using a serial absolute / incremental encoder.
Rated output power: 7.0kw.
Rated speed: 2000rpm.
With the brake: without.
Shaft end: straight shaft.
The rotor of AC servo motor is usually made of squirrel cage, but in order to make the servo motor has a wide range of speed regulation, linear mechanical properties,
Without the "rotation" phenomenon and the performance of the fast response, it is compared with the ordinary motor,
The two characteristics of rotor resistance and moment of inertia should be provided A2ACPUP21
At present, there are two kinds of rotor structure, one is the squirrel cage rotor, which is made of conductive material with high resistivity,
In order to reduce the moment of inertia of the rotor, the rotor is slender.MITSUBISHI inverter series: FR-A820.
Voltage level: three phase 200V.
Power: 15kw.
SLD converter rated current: 77A.
Structure and function: Standard model.
Type: CA.
Substrate coating: have.
Parameters can be selected by 4 different rated current and different overload rating (SLD (ultra light load) rated, LD (light load) rating, ND (general load) rating, HD (weight).
Type load) for selection.
You can choose the most suitable frequency converter for use; and by selecting a transducer with a SLD or LD rated level,
Be able to reduce the size of the device (compared with the FR-A700 series, to reduce the volume of equipment).
For applications that require high torque at low speeds, the HD rating is the most suitable.
The controller is used to control and monitor the frequency converter through the network.
Standard corresponding RS-485 communication (MITSUBISHI converter protocol, Modbus-RTU protocol) data transmission speed up to 115200bps. Bus connector conversion cable packageFunction: simple motion control 4 axis positioning (corresponding to SSCNET III /H).
Input and output points: 8 points.
Positioning control via /H III SSCNET.
FX5-40SSC-S is equipped with the corresponding SSCNET III /H 4 axis positioning function module.
Table operation, combined with linear interpolation, circular interpolation between the 2 axes, and the connection trajectory control,
Smooth positioning control can be easily realized.
Positioning function of 8CH high speed pulse input and 4 axis pulse output by FX5U/FX5UC.
In addition, the high speed output can be set through the table, which can be realized through special instructions, which can be used to realize the function of interrupt location, variable speed operation and simple interpolation.
A2ACPUP21 Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=A2ACPUP21&select=5
