MITSUBISHI MITSUBISHI Q312B Price

Points: 32 points
.
Rated voltage: DC24V.
Connection type: connector
.
Three remote components can be connected to the CC-LINK system.
Remote I/O: refers to those who require only the ON/OFF control function of the field components, such as digital I/O or pneumatic valve, etc..
In this type of communication can only be carried out in the bit data.
Remote components: refers to those that require processing of the register data of the field components, such as analog I/O and counters, etc Q312B.
In this type of component, in addition to the bit data can be carried out in the register data communication.
Intelligent remote: this type of component is to allow the main station or other stations to access the action, to collect data and control the local PLC station,
GOTS and programmer interface unit are of this type. MITSUBISHI inverter series: FR-A820.
Voltage level: three phase 200V.
Power: 45kw.
SLD converter rated current: 233A.
Structure and function: Standard model.
Type: CA.
Substrate coating: have.
Parameters can be selected by 4 different rated current and different overload rating (SLD (ultra light load) rated, LD (light load) rating, ND (general load) rating, HD (weight).
Type load) for selection.
You can choose the most suitable frequency converter for use; and by selecting a transducer with a SLD or LD rated level,
Be able to reduce the size of the device (compared with the FR-A700 series, to reduce the volume of equipment).
For applications that require high torque at low speeds, the HD rating is the most suitable.
The controller is used to control and monitor the frequency converter through the network.
Standard corresponding RS-485 communication (MITSUBISHI converter protocol, Modbus-RTU protocol) data transmission speed up to 115200bps. Cable length 1.2 meters.
Extended substrate for connection.MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 3.5kw.
Interface type: SSCNET type III fiber communication.
Special specification: suitable for direct drive servo motor.
Power specification: three phase AC200V.
Direct drive system suitable for high speed and high precision!
High speed operation can be realized by direct drive (2m/s), and the traditional mechanical transmission can not achieve such a high speed.
The full closed loop control can be realized by using the position feedback signal from the load side encoder, such as the linear encoder.
The use of a flexible linear servo motor drive components can make the system more compact structure.
The primary side of the linear servo motor (motor coil) is sliding along the secondary side (permanent magnet) of the motor,
So linear servo motor is especially suitable for large range of applications. In addition, linear servo motor can be connected in series,
Especially for large systems in two axes for high precision synchronous operation.
Q312B Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=Q312B&select=5
