MITSUBISHI MITSUBISHI QY81P Price

1 channels.
Input (weighing sensor output): V/V 0.0~3.3m.
Output (resolution): 0~10000.
Conversion speed: 10ms.
18 point terminal.
Weighing sensor input module capable of directly connecting with all kinds of weighing sensor.
The weighing sensor can now be directly connected to a programmable controller system,
Without the need for an external connection to the signal converter, etc..
By ensuring the accuracy of the weighing sensor, stable data conversion speed,
To achieve a high precision measurement QY81P
No external signal converter!
The weighing sensor input module is directly connected to the programmable controller, which can reduce the time and cost of the sensor!
Various types of weighing sensors can be connected with the magnetostrictive type, capacitive type, rotary instrument or strain gauge.
Can connect 6 wire system (combined with remote sensing technology and ratio method) or 4 wire system weighing sensor. Servo motor series: medium inertia, medium power.
Rated output: 2.0kw.
Rated speed: 1000r/min.
Electromagnetic brake: with.
Shaft end specification: Standard (straight axis).
Characteristics: medium inertia has two types of low speed and high speed, suitable for different applications.
IP level: IP67.
Application example:
1, material handling system.
2, industrial robots.
3, X-Y working table.
The protection level of the HF-SP/HF-JP series servo motor is IP67 (except the shaft part).
Motor capacity selection soft (MRZJW3-MOTSZ111E)
Friendly interface design, only in the mechanical description window input constant and operation mode can choose the best servo amplifier,
The servo motor and the regenerative braking options, but also in the selection window in the selection of linear servo motor and direct drive motor.
Characteristic
(1) 10 typical mechanical transmission structure can be used to choose
(2) user defined operating modes (location and speed control)
(3) in the selection process, the feed speed and torque can be displayed in a graphical format.
(4) the calculation process can be displayed
Can easily calculate the power of the servo motor free software!
QY81P Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=QY81P&select=5
