>> AJ65BT-64DAI Analog output module
AJ65BT-64DAI Analog output module
MITSUBISHI AJ65BT-64DAI Manual And Instructions
AJ65BT-64DAI datasheetPDF datasheet
MITSUBISHI AJ65BT-64DAI Product information and technical parameters：
Brand: MITSUBISHI
Name: Analog output module
Model: AJ65BT-64DAI
Screw, 2 piece type terminal.
Current output module.
Number of channels: 4 channels.
Number of stations: 2 stops.
Station type: remote equipment station.
High speed data transfer of up to 10Mbps;
The development of CC-LINK is not only to meet the control of high speed remote I/O,
But also to meet the high speed of the field of information control.
In order to achieve this goal, the transmission speed of CC-LINK is compared with that of the previous live network system to add 40 to 10Mbps.
Such a high speed can not affect the speed of the machine control while allowing a large number of data communication.
