F9GT-HCAB4-3M Cable for connecting hand held GOT and PLC

Series introduction: set a number of basic functions in a small body model.
Screen size: 3.7 inches.
Display color: monochrome.
Mounting type: panel mounting type.
Resolution: 288 * 96.
Display device: STN monochrome.
Host frame color: black.
Power type: DC24V.
Communication interface: with built-in RS-232 F9GT-HCAB4-3M.
Set a number of basic functions in a compact type.
GT1055/GT1050/GT1045/GT1040:
User storage capacity: 3MB F9GT-HCAB4-3M
Device USB port.
The standard RS-422/485 and RS-232 interface.
GT1030/GT1020:
User storage capacity: 1.5MB (gt1030) /512kb (gt1020).
Three color LED backlight design, equipment status at a glance.
The standard RS-422/485 or RS-232 interface.
Touch screen, also known as touch screen, touch panel, is a kind of induction type liquid crystal display device can receive contacts and other input signals,
When touching the screen button on the screen,
The tactile feedback system on the screen can drive various connecting devices according to the pre programmed program,
Can be used to replace the mechanical button panel, and by the liquid crystal display screen to create the image of the effect of birth F9GT-HCAB4-3M F9GT-HCAB4-3M. MELSECNET/B.
Twisted pair bus. Cable length: 20m.
Connection between serial communication unit and GOT.
Connection between a computer link unit and a GOT.
Applicable models: GT16, GT15, GT11, HandyGOT, GT10, GT27, GT25, GT23,, GT21. Features: high cost of second models.
Picture size: 10.4 inches.
Resolution: VGA.
Display: TFT color.
Panel color: black.
Power type: AC100~240V.
Specification rich, design at ease
GT23 standard supports SD memory card and standard equipped with Ethernet, RS-232, RS-422/485, host/device USB interface.
Support log, one to many connections, FA transparent transmission and other diverse FA machine related functions.
System configuration diagram shows in order to form the connection with the GOT programmable controller system,
Easily confirm module status. In addition, after touching each module,
Can start its corresponding expansion function, to facilitate system maintenance, shorten the time of failure.
1, simple design
In order to cope with the use of a variety of scenarios, to abandon all the nonsense of the decoration, the use of straight tone of the minimalist design.
2, plane body
Surface mining pure plane design, easy to clean. (USB interface at the back)
3, Ethernet interface
Up to 2 different manufacturers can be connected to the FA machine.
4, RS-232 interface
Can connect all kinds of FA machine, bar code reader, serial printer.
5, RS-422/485 interface
Can be connected to a variety of FA machines, bar code reader.
6, USB interface: device USB (Mini-B USB)
Can connect to the computer to transfer data.
7, USB interface: host USB (USB-A)
USB data can be transmitted through the USB memory or read log data, such as the GOT data, but also can be conneected to the use of the mouse, keyboard F9GT-HCAB4-3M.
8, SD memory card slot
Can save alarm and log data, such as a large number of data.
Can be collected through the GOT programmable controller, temperature regulator and other data, and to chart, list display F9GT-HCAB4-3M.
Computer analysis can also be used to save the data. Even in the case of a power outage, the log data can be saved to the built-in SRAM.
