GT15-60ATT-96 Enclosure

For the GT1685M-STB.
Applicable model: GT16. 8.4 inches.
Applicable models: GT27, GT25, GT23. Cable length: 13m.
The connection between the CC-LINK interface unit and the smart GOT.
Applicable model: HandyGOT. Cable length: 1.2m.
For the connection between the two graphic operations.
Applicable models: GT16, GT15, GT11 GT15-60ATT-96. Cable length: 3 meters.
For QnA/A/FX (FX1, FX2, FX2C) CPU and GOT connection between GT15-60ATT-96
For connection between FA-CNV_CBL and GOT.
For connection between FX-2PIF and GOT.
For connection between FX-422AW0 and GOT.
For serial communication module AJ71QC24 (N) -R4 and GOT connection between.
For connection between AJ65BT-G4-S3 and GOT. For connection between personal computer (USB) and GOT (RS-232) (adapter and personal computer through GT09-C30USB-5P) GT15-60ATT-96.
Applicable model: GT10. Cable length: 20m.
The connection between the FXCPU (MINI-DIN8 pin connector) and the graphic operation terminal.
Connection between FXCPU communication function extension board (MINI-DIN8 pin connector) and GOT.
Applicable models: GT10, GT21. 256MB flash ROM.
Applicable models: GT16, GT15, GT11, HandyGOT GT15-60ATT-96. Features: high cost of second models.
Picture size: 8.4 inches.
Resolution: VGA.
Display: TFT color.
Panel color: black.
Power type: DC24V.
Specification rich, design at ease
GT23 standard supports SD memory card and standard equipped with Ethernet, RS-232, RS-422/485, host/device USB interface.
Support log, one to many connections, FA transparent transmission and other diverse FA machine related functions.
System configuration diagram shows in order to form the connection with the GOT programmable controller system,
Easily confirm module status. In addition, after touching each module,
Can start its corresponding expansion function, to facilitate system maintenance, shorten the time of failure.
1, simple design
In order to cope with the use of a variety of scenarios, to abandon all the nonsense of the decoration, the use of straight tone of the minimalist design.
2, plane body
Surface mining pure plane design, easy to clean. (USB interface at the back)
3, Ethernet interface
Up to 2 different manufacturers can be connected to the FA machine.
4, RS-232 interface
Can connect all kinds of FA machine, bar code reader, serial printer.
5, RS-422/485 interface
Can be connected to a variety of FA machines, bar code reader.
6, USB interface: device USB (Mini-B USB)
Can connect to the computer to transfer data.
7, USB interface: host USB (USB-A)
USB data can be transmitted through the USB memory or read log data, such as the GOT data, but also can be conneected to the use of the mouse, keyboard GT15-60ATT-96.
8, SD memory card slot
Can save alarm and log data, such as a large number of data.
Can be collected through the GOT programmable controller, temperature regulator and other data, and to chart, list display GT15-60ATT-96.
Computer analysis can also be used to save the data. Even in the case of a power outage, the log data can be saved to the built-in SRAM.
