MITSUBISHI GT16M-ROUT Product information and technical parameters：
Brand: MITSUBISHI
Name: RGB output unit
Model: GT16M-ROUT
1 channels for analog RGB output.
Applicable model: GT16.
...More relevant models >>>>
