HC-KFS13K Low inertia small power motor
MITSUBISHI HC-KFS13K Manual And Instructions
HC-KFS13K datasheetPDF datasheet
MITSUBISHI HC-KFS13K Product information and technical parameters：
Brand: MITSUBISHI
Name: Low inertia small power motor
Model: HC-KFS13K
Motor series: low inertia, low power.
Rated output power: 0.1kw.
Rated speed: 3000r/min.
Whether with brake: No.
Shaft end: key shaft (open slot).
Protection level: IP55 does not include the shaft part and the connector.
Features: low inertia is particularly suitable for high speed motor (6000 or 12000 RPM / min) of general industrial machinery.
Application example 1: drive belt drive, robot.
Application example 2: assembly machine, sewing machine, X-Y working table.
Application example 3: food manufacturing machinery, semiconductor manufacturing equipment, knitting machine and embroidery machine.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring.
