HG-SN52BJ-S100 Electric machinery
MITSUBISHI HG-SN52BJ-S100 Manual And Instructions
HG-SN52BJ-S100 datasheetPDF datasheet
MITSUBISHI HG-SN52BJ-S100 Product information and technical parameters：
Brand: MITSUBISHI
Name: Electric machinery
Model: HG-SN52BJ-S100
Servo motor series: low inertia, small capacity.
Rated output: 0.5kw.
Rated speed: 2000r/min.
Electromagnetic brake: there.
Oil seal: have.
Corresponding servo amplifier: MR-JE-10B/MR-JE-10A.
Support position control, speed control, torque control, push and press control.
Position control can use linear, arc interpolation controller, fixed size feed control, target position change and other rich functions.
The position control and torque control are realized by switching control mode.
The gain adjustment of servo can be simply performed by the advanced one key tuning function.
At the same time, it is also able to suppress the low frequency vibration of the manipulator by the advanced vibration suppression control II,
Shorten the time to complete the positioning, so as to achieve the production of the rhythm of the shortening.
