MITSUBISHI MR-J3-20B Product information and technical parameters：
Brand: MITSUBISHI
Name: SSCNET type III optical fiber communication driver
Model: MR-J3-20B
MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 0.2kw.
Interface type: SSCNET type III fiber communication.
Power specification: single phase AC200V.
High speed serial communication between the SSCNET and the servo amplifier by using the fastest up to 0.44ms communication cycle,
A fully synchronous control system can be constructed.
It is only necessary to insert the special optical fiber into the joint to form SSCNET III network, which greatly reduces the wiring work and reduces the possibility of false wiring.
Due to the adoption of the optical fiber communication, the anti noise ability can be greatly improved and the long distance wiring of 50 meters (maximum 800 meters x 16 axes) can be realized.
A servo amplifier to meet the full closed loop control function MR-J3-B-RJ006.
Suitable for mechanical servo optimization and adjustment!
More advanced optimization adjustment function and control function to maximize mechanical properties.

Motor series: medium inertia, medium power.
Rated output power: 0.5kw.
Rated speed: 3000r/min.
Whether to take the brake: No.
Shaft end: Standard (straight).
Protection level: IP65 (IP67).
Features: medium inertia from low speed to high speed three modes for selection, suitable for different applications MR-J3-20B.
Application examples: transmission machinery, robots, X-Y working platform.
High resolution encoder 131072p/rev (17 bit) MR-J3-20B
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring. Drive: MR-H_AN series.
Rated output: 7.0KW.
Universal AC servo.
Servo driver (drives servo) also known as the "servo controller", "servo amplifier",
Is a kind of controller used to control the servo motor MR-J3-20B. Its function is similar to that of the frequency converter,
Belongs to a part of the servo system, which is mainly used in high precision positioning system.
In general, the servo motor is controlled by position, speed and torque in three ways,
To achieve high precision positioning of the transmission system, the current transmission technology is the high-end products MR-J3-20B.
Servo drive is an important part of modern motion control,
Is widely used in industrial robots and CNC machining centers and other automation equipment.
In particular, it has become a hot research topic in the field of servo drives for the control of AC permanent magnet synchronous motor.
Current, speed and position 3 closed loop control algorithm based on vector control is widely used in AC servo drive system.
The speed closed-loop design of the algorithm is reasonable or not, for the entire servo control system,
Especially the speed control performance plays a key role.MITSUBISHI general purpose AC servo amplifier MELSERVO-J2-Super series.
Rated output: 0.2kw.
Built in program operation.
Voltage: 3 phase AC200VAC or single phase AC230V.
Super function, excellent performannce MR-J3-20B.
High performance CPU integration, greatly improve product responsiveness.
Due to the application of high performance CPU, so that the response can be greatly improved.
Speed loop frequency response increased to more than 550HZ.
MR-J2--Super series is the best device for high speed positioning applications MR-J3-20B.
Easy adjustment.
Model adaptive control / advanced real time automatic tuning.
