Fiber length: 3 meters.
SSCNET III cables (standard optical fiber used in control cabinet).
Joints for CN1A and CN1B.
Motor series: low inertia, medium capacity.
Rated output power: 15.0kw.
Rated speed: 1000rpm.
With the brake: without.
Shaft end: straight shaft.
The rotor of the servo motor is a permanent magnet, which is controlled by the U/V/W,
The rotor rotates under the action of the magnetic field, and the encoder feedback signal of the motor is given to the driver,
According to the feedback value and the target value, the driver adjusts the rotation angle of the rotor MR-J3BUS3M
MR-J3BUS3M
Accuracy of the servo motor depends on the accuracy of the encoder (number of lines). Motor series: low inertia, medium power.
Rated output power: 37.0kw.
Rated speed: 1500r/min.
Whether to take the brake: No.
Shaft end: Standard (straight) MR-J3BUS3M.
Voltage: 400V type.
Protection level: IP65 (IP67).
Features: low inertia from low speed to high speed, three modes can be selected, suitable for different application range. As a standard port, 30KW or greater power is suitable for flange (type) installation and support foot mounting.
Application example: injection molding machine, semiconductor manufacturing equipment, large conveyor machinery MR-J3BUS3M.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring. Motor series: medium inertia, medium power.
Rated output power: 3.5kw.
Rated speed: 3000r/min.
Whether to bring the brakes: with.
Shaft end: Standard (straight).
Protection level: IP65 (IP67).
Features: medium inertia from low speed to high speed three modes for selection, suitable for different applications.
Application examples: transmission machinery, robots, X-Y working platform.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring. Drive: MR-H_ACN series CC-LINK features.
Rated output: 0.4KW.
The test system is composed of two parts, namely, the servo driver, the motor system and the host computer.
The host computer sends the speed command signal to the servo driver,
Servo drives start to run in accordance with the instructions.
In the course of operation, the running data of the servo system is collected by the host computer and the data acquisition circuit,
And carries on the preservation, the analysis and the display to the data. Because the motor is not loaded in this test system,
So compared with the previous two kinds of testing systems, the system has a relatively small voolume,
And the measurement and control circuit of the system is relatively simple,
But it also makes the system can not simulate the actual operation of the servo drive MR-J3BUS3M.
Usually, such testing system is only used to test the rotational speeed and angular displacement of the tested system under no-load condition,
And can not carry on the comprehensive and accurate test to the servo drive MR-J3BUS3M.
