R16SFCPU-SET Safety CPU
MITSUBISHI R16SFCPU-SET Manual And Instructions
R16SFCPU-SET datasheetPDF datasheet
MITSUBISHI R16SFCPU-SET Product information and technical parameters：
Brand: MITSUBISHI
Name: Safety CPU
Model: R16SFCPU-SET
Safety grade (SIL): SIL 3 (IEC 61508).
Performance level (PL): e PL (13849-1 EN/ISO).
Operation control mode: stored procedures repeated operation.
Program capacity: 160K (security program: 40K).
Program memory: 640K.
Soft element / tag memory: 1710K.
Data memory: 10M.
Integrate security functions into the control system.
Can be used in the previous iQ-R MELSEC series module as a general control purposes,
Use on the same substrate, it can be used to construct a hybrid system with general control and safety control.
Moreover, IE Field CC-Link network can be integrated with general communication and secure communication,
Ethernet cable can also be used in secure communication,
No need to use a dedicated cable, etc..
In line with the international safety standards for the safety of CPU can be controlled at the same time the general system and safety system.
Available through IE Field CC-Link network,
Connect the safety switch and safety light curtain system used to secure CPU,
System for the construction of a general control and safety control system.
In addition, through the use of intuitive engineering software Works3 GX,
Focus on general control and safety control programming.
