MITSUBISHI MITSUBISHI A1SX42 Price

Superior high efficiency IPM motor.
Output power: 30kw.
Rated speed: 1500r/min.
Voltage level: 400V.
IPM motor MM-EFS series can not be used to run the power frequency power.
The total wiring length of the IPM motor shall not exceed 100m.
1 inverters can not connect multiple IPM motors at the same time. Motor series: low inertia, medium and small capacity.
Using a serial absolute / incremental encoder A1SX42
Rated output power: 0.4kw.
Rated speed: 3000rpm.
With the brake: without.
Shaft end: straight shaft.
Comparison of single phase induction motor and servo motor.
The working principle of the AC servo motor is similar to that of the single phase induction motor,
But the rotor resistance of the former is much larger than that of the latter,
So the servo motor is compared with the single machine asynchronous motor,
There are three notable features:
1, large starting torque.
2, a wide range of operation.
3, no rotation phenomenon.
AC servo motor running smoothly, low noise.
But the control characteristic is non-linear, and because the rotor resistance is big, the loss is big, the efficiency is low,
Therefore, compared with the same capacity DC servo motor, the volume is large and the weight is heavy,
So it is only suitable for 0.5-100W small power control system. Display and setting data in a programmable controller.
Can monitor or set the timer, counter, data register.
Half the 16 characters *4, full width of 8 characters, Japanese *4 (JIS first, second), English digital. Motor series: low inertia, small capacity.
Using a serial absolute / incremental encoder.
Rated output power: 0.1kw.
Rated speed: 3000rpm.
With a brake band.
Shaft end: straight shaft.
AC servo motor and brushless DC servo motor in the function of the difference: AC servo is better, because it is a sine wave control, torque ripple small.
DC servo is a trapezoidal wave. DC servo is simple and cheap. Motor series: medium inertia, medium power.
Rated output power: 2.0kw.
Rated speed: 2000r/min.
Whether to bring the brakes: with.
Shaft keyway: (open slot).
Protection level: IP65 (IP67).
Features: medium inertia from low speed to high speed three modes for selection, suitable for different applications.
Application examples: transmission machinery, robots, X-Y working platform.
High resolution encoder 131072p/rev (17 bit).
The encoder with high resolution ensures excellent performance and stability at low speed.
All motor dimensions are the same as before and all are compatible with the wiring.

A1SX42 Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=A1SX42&select=5
