MITSUBISHI MITSUBISHI L06CPU-CM Price

MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 11.0kw.
Interface type: SSCNET type III fiber communication.
Special specification: suitable for direct drive servo motor.
Power specification: three phase AC200V.
Direct drive system suitable for high speed and high precision!
High speed operation can be realized by direct drive (2m/s), and the traditional mechanical transmission can not achieve such a high speed L06CPU-CM
The full closed loop control can be realized by using the position feedback signal from the load side encoder, such as the linear encoder.
The use of a flexible linear servo motor drive components can make the system more compact structure.
The primary side of the linear servo motor (motor coil) is sliding along the secondary side (permanent magnet) of the motor,
So linear servo motor is especially suitable for large range of applications. In addition, linear servo motor can be connected in series,
Especially for large systems in two axes for high precision synchronous operation. MITSUBISHI inverter FR-F720 series.
Voltage level: three phase 200V.
Frequency converter capacity: 30KW.
When the ring is opened, the frequency converter is provided with a load of the motor when the motor is operated with a load at a given frequency,
The range of the motor speed in the rated slip ratio (1%~5%) changes.
For the requirements of relatively high precision, even if the load changes are also required to operate at a given speed of the occasion,
Inverter with PG feedback function can be used (selection).
If the given acceleration time is too short, the output frequency of the inverter is far more than the change of the speed (electric angular frequency),
Converter will be due to flow over the current trip, the operation stopped, which is called stall. Max input / output points: 24 points.
Power supply voltage: DC24V.
Input points: 14 points.
Output points: 10 points.
Output type: relay.
Power consumption (W): 32.
Weight (kg):0.5.
Size (WxHxD) mm:90x90x75.
FX1N series is a very powerful micro PLC, can be extended to up to 128 I/O points,
And can increase the special function module or the expansion board.
Communication and data link function options make FX1N in the volume, communication and special function modules and other important applications is very perfect.
A PLC unit can output 2 100KHz pulses at the same time,
PLC is equipped with 7 special positioning instructions,
Including zero return, absolute position readout, absolute or relative drive, and special pulse output control.
L06CPU-CM Operation manual / Instructions / Catalog download link: /searchDownload.html?Search=L06CPU-CM&select=5
