FA-TB18XY Conversion module

Convert connectors to fast connectors.
According to the location of the connection equipment distribution module. The connector is converted to a screw relay terminal.Can be isolated to obtain DC24/48/100V, AC100/200V input signal.Output points: 16 points.
Rated output voltage: DC24V/AC240V.
Rated open and close current: 2A/1 point FA-TB18XY.
Common way: 16 point / public end.
Input / output occupied points: 16 points (I/O distribution: output 16 points) FA-TB18XY
External wiring connection: 18 point terminal.
The switch input and output module is a device which can collect the input / output of the switch signal,
Digital I/O modules are often called.
The switch signal is collected to the computer or the computer to send the relevant instructions through the RS-485 bus to control the switch of the switch,
Can also be carried out through the RS-485 bus communication,
Remote control switch FA-TB18XY.
Communication protocol is a standard Modbus protocol or custom protocol. "IE Field CC-Link master / local station
Transmission speed: 1Gbps.
Remote input / output: 16384 points.
Remote register: 8192 words.
Can be applied to the serial number of the top 5 for the "13012" and after the CPU module FA-TB18XY.
Simply set the parameters, you can easily start the network.
Simply use the Works2 GX, set the network parameters in the 1 master station, you can easily connect all the slave stations.
Also, when you need to change the system, you only need to change the parameters.
High degree of freedom network
Build star, linear, star and linear mixed model, and ring network,
Therefore, can freely set the scene equipment.
When you use HUB, you just need to connect the cable to the free port to build the network easily,
Additional equipment and re layout of the corresponding is also more simple. "Convert connector to screw relay terminal.
The action of the signal of the conversion module is shown in the light of the lamp.
Negative common end with display. Transmission speed: 100Mbps/10Mbps.
MELSOFT connection.
SLMP cross letter (MC protocol).
Communication protocol support function.
E-mail function.
Web function.
Collect / change CPU module data from the other side of the device.
SLMP (MC protocol) communication
SLMP is a protocol that uses Ethernet to access SLMP devices from the other device.
If it is possible to follow the SLMP control procedures to send and receive messages to the device,
The communication can be carried out by SLMP. MC can also support the previous agreement.
MELSOFT connection
Can be connected with the programming tool Works2 GX and other MELSOFT products.
In addition, through the use of communication tools to support the sale of (MX Componennt),
Regardless of the details of the protocol (how to send and receive procedures),
Can create a communication program on the upper side of the system FA-TB18XY.
It can easily connect to BACnet and MODBUS /TCP
Communication protocol support functioon
Through the Works2 GX communication protocol support function, can easily set the communication with the other equipment required for the agreement FA-TB18XY.
