MITSUBISHI HF-SP202 Product information and technical parameters：
Brand: MITSUBISHI
Name: Medium inertia power servo motor
Model: HF-SP202
Servo motor series: medium inertia, medium power.
Rated output: 2.0kw.
Rated speed: 2000r/min.
Electromagnetic brake: No.
Shaft end specification: Standard (straight axis).
Characteristics: medium inertia has two types of low speed and high speed, suitable for different applications.
IP level: IP67.
Application example:
1, material handling system.
2, industrial robots.
3, X-Y working table.
The protection level of the HF-SP/HF-JP series servo motor is IP67 (except the shaft part).
Motor capacity selection soft (MRZJW3-MOTSZ111E)
Friendly interface design, only in the mechanical description window input constant and operation mode can choose the best servo amplifier,
The servo motor and the regenerative braking options, but also in the selection window in the selection of linear servo motor and direct drive motor.
Characteristic
(1) 10 typical mechanical transmission structure can be used to choose
(2) user defined operating modes (location and speed control)
(3) in the selection process, the feed speed and torque can be displayed in a graphical format.
(4) the calculation process can be displayed
Can easily calculate the power of the servo motor free software!

Motor series: low inertia, small capacity.
Using a serial absolute / incremental encoder.
Rated output power: 0.2kw.
Rated speed: 3000rpm.
With the brake: not with brake.
Without GB.
Shaft end: straight shaft.
A servo motor is an engine that controls the operation of the mechanical components in the servo system HF-SP202.
Servo motor can make the control speed, position accuracy is very accurate, can be converted to torque and speed voltage signals to drive the control object HF-SP202
Servo motor rotor speed is controlled by the input signal, and can quickly response,
In the automatic control system, used as actuators, and electromechanical time constant, high linearity, initiating voltage characteristics,
The signal can be converted into a motor shaft on the angular displacement or angular velocity output HF-SP202.
Divided into DC and AC servo motor two major categories, the main features are,
When the signal voltage is zero, there is no rotation,
The speed increases with the increase of the torque and the speed decreases. MITSUBISHI motor universal AC servo amplifier MELSERVO-J3 series.
Rated output: 1.0kw HF-SP202.
Interface type: SSCNET type III fiber communication.
Special features: integrated driver security.
Power specification: three phase AC400V.
STO function as a security feature is added to the SSCNET III fiber communication type servo amplifier.
By using the STO function, the electromagnetic contactor used in the past to prevent the motor from accidentally starting is no longer needed.
SS1 functions can be realized by using the MR-J3-D05 security logic unit.
MR-J3-BS uses a full closed loop control system.
Compatibility with MR-J3-B.
MRR-J3-BS installation, wiring and connectors are the same as the MR-J3-B, so do not change the existing connection will be easy to MR-J3-B
Change to MR-J3-BS HF-SP202.
Security functions are connected to the CN8 interface through an external securityy circuit to increase the MR-J3-BS driver security HF-SP202.
Compatible full closed loop control system.
MR-J3-BS has a full closed loop control system version.
