Q173NCCPU-S01 CNC numerical control CPU

MITSUBISHI Q173NCCPU-S01 Manual And Instructions
Q173NCCPU-S01 datasheetPDF datasheet
Q173NCCPU-S01 datasheetPDF datasheet
Q173NCCPU-S01 Special InstructionsStrctured Programming Manual
Q173NCCPU-S01 Application FunctionsStrctured Programming Manual
Q173NCCPU-S01 Common InstructionsStrctured Programming Manual
Q173NCCPU-S01 FundamentalsStrctured Programming Manual
Q173NCCPU-S01 Multiple CPU SystemUser's Manual
Q173NCCPU-S01 Function Explanation, Program FundamentalsUser's Manual
Q173NCCPU-S01 Hardware Design, Maintenance and InspectionUser's Manual
Q173NCCPU-S01 Structured TextProgramming Manual
Q173NCCPU-S01 MELSAP-LProgramming Manual
Q173NCCPU-S01 SFCProgramming Manual
Q173NCCPU-S01 PID Control InstructionsProgramming Manual
Q173NCCPU-S01 Common Instructions 1/2Programming Manual
Q173NCCPU-S01 Structured Text(ST)Programming Guide Book

MITSUBISHI Q173NCCPU-S01 Product information and technical parameters:
Brand: MITSUBISHI
Name: CNC numerical control CPU
Model: Q173NCCPU-S01
Set high performance CNC and high speed programmable controller as a whole.
Integrating the high performance CNC with the high speed programmable controller helps to shorten the overall cycle time.
Support a rich variety of FA modules, can be flexible to meet the needs of different applications.

Input / output points: 4096 points.
Number of input and output elements: 8192.
Program capacity: 200 K step.
Processing speed: 0.0095 s.
Program memory capacity: 800 KB.
Support USB and network.
Support installed memory card.
Providing high speed communication between multiple CPU.
Shorten the fixed scan interrupt time, high precision device Q173NCCPU-S01.
The minimum interval of the fixed period interrupt program is reduced to 100 s Q173NCCPU-S01
The high speed signal can be accurately obtained, which makes the contribution to the higher precision of the device.
High speed and high precision machine control by multi CPU.
By parallel processing of the linear and multi CPU high-speed communication (cycle 0.88ms) of the parallel control program, the high speed control Q173NCCPU-S01.
Multi CPU high speed communication cycle and motion control synchronization, so it can achieve the maximization of computing efficiency.
In addition, the latest movement control CPU in performance is 2 times the previous model,
To ensure high speed and high accuracy of the machine control.8 axes.
Connect SSCNET III.
Control unit: pulse.
Location data: 32 data / axis Q173NCCPU-S01.
Ideal solution for simple multi axis positioning.
A variety of functions, such as positioning control, constant velocity control, and other positioning control systems.
The multi axis system is most suitable for simple positioning control.
Ideal selection for high speed linear positioning control in multi axis system.
Linear interpolation operation with up to 4 axes can be carried out.
With the electronic gear, gap compensation, absolute position system, such as basic positioning function. Extended SRAM card 2MB
Better user experience data recording function.
Easy to record, no need to program.
SSimply through the special configuration tool wizard to easily complete the settings,
The collected data can be saved in CSV format to SD storage card Q173NCCPU-S01.
Can be effectively used to save the CSV file to facilitate the creation of a varietty of reference materials,
Including daily reports, generate reports and general reports Q173NCCPU-S01.
These data can be applied to the data analysis, tracing, etc..
